Excellent pulse compression: Pulse width under 50fs for ultrafast laser applications.
High system compatibility: Supports integration with HCF systems.
Superior stability: 24/7 operation with <0.24% RMS power fluctuation.
Efficient energy transfer: Over 80% compression efficiency.ent environments.
Easy operation and installation: Simple setup, adaptable to various environments.
Wide applications: Ideal for micro/nano processing, precision manufacturing, and more.
The HYPERION-S series is a pulse compressor using nonlinear technology to compress input laser pulses through spectral broadening. It features advanced cavity design and high-quality femtosecond optics for minimal transmission loss. The built-in monitoring system ensures stable pulse output by checking the spot quality in real time.
This pulse compressor offers excellent interference resistance, long lifespan, and can provide 5-10 times pulse compression, making it ideal for high-power, high-repetition-rate Yb femtosecond lasers.
| Parameter | HYPERION-S |
| Incident pulse width | 150fs-1ps |
| Incident pulse energy | 400 - 2000μJ |
| Incident laser central wavelength |
1030 ± 10nm |
| Maximum compatible power |
80W |
| Typical compression ratio | 5-10 |
| Compressor efficiency | >90% |
| Typical output pulse width | <50fs |
| Compatibility | Can be cascaded with HCF system to output few-cycle pulses |
| Dimensions (L×W×H) | 425.5 x268 x 146 mm (LxWxH) |
| Weight (kg) | 18kg |
|
Remaining weight(kg)
|
24kg（Water-Cooled Machine）
|
|
Power supply requirements
|
AC220V/10A
|
|
Power supply requirements for
|
220V/0.6-5.6A/10.2kW（CWUP-10AI）
|
